Flextube Watertube

The “Flexible Water Tube” design provides for extremely fast, natural internal circulation, resulting in maximum heat transfer and operating efficiency. Dependency on external pumps is eliminated. The unique flexible bent tube design reduces all possible damage from thermal shock and related problems.
parker boiler logo

PARKER – The Parker Boiler Co. was founded in 1946 and is a world-renowned manufacturer of industrial and commercial steam boilers from 1.5 H.P. to 150 H.P. with pressures to 250 PSI capable of delivering dry steam in under 10 minutes. We manufacture industrial and commercial direct-fired hot water boilers (available as gas, oil, propane, or combination-fired) ranging from 300,000 to 6,800,000 BTU, with operating temperatures to 400°F degrees and pressures to 300 PSI, Condensing Boilers 399,000 BTU to 5,433,000 BTU up to 180°F and 80 PSI. Our indirect-fired water heaters (available as gas or propane-fired) range from 300,000 to 3,000,000 BTU input, with operating temperatures to 190°F degrees and pressures to 150 PSI. We manufacture high temperature thermal liquid heaters (available as gas, oil, propane, or combination-fired) for process-heating up to 650°F degrees, ranging from 126,000 to 6,250,000 BTU input. We also are the makers of low NOx steam and hot water boilers and burner systems. Most models are UL or ETL listed. In addition to manufacturing our products, Parker Boiler is in the business of providing expertise and support to our customers.

PRECISION – The Precision FTH Series “Flex-Tube” boiler is a two drum system with multiple longitudinal pass separated by tangent water walls resulting in long turbulent gas travel without gas stratification. The furnace is fully water-cooled on all four sides and heat absorption does not exceed 60,000 BTU per cubic foot of furnace volume. Large downcomers are located outside the heat transfer zones to ensure positive natural circulation without relying on external circulation pumps. The boiler drums are independently supported by a structural steel frame to ensure that undue stress is not placed on the heat exchanger assembly.

Features

  • Compact patented design is unique in the industry providing an unmatched compact footprint
  • Large square furnace promotes lower emissions
  • Packaged boiler capacities from 10,000 lb/hr to 200,000 lb/hr
  • Design pressures up to 2,000 PSIG
  • Superheated steam temperatures up to 900°F
  • Gas outlet options: top, left or right side
  • Suitable for natural gas, oil, refinery gas, off gases
  • Field erect designs available
  • Robust long lasting design, +30 years lifespan
  • Windbox mounted FD fan for capacities 120KPPH and under



The D-Type industrial watertube boiler has allowed English Boiler to offer attractive pricing programs without sacrificing quality construction, efficiency, guaranteed emissions, and on time delivery.

Features

  • Large Furnace assures complete combustion and lower emissions
  • Packaged boiler capacities from 10,000 lb/hr to 550,000 lb/hr
  • Dual burner design on capacities over 300kpph
  • Saturated and/or Superheated Steam
  • Design pressures up to 2,000 PSIG
  • Superheated steam temperatures up to 900°F
  • Gas outlet left or right side at front
  • Suitable for natural gas, oil, refinery gas, off gases
  • Field erect designs available
  • Robust long lasting design, +30 years lifespan
  • Windbox mounted FD fan for capacities 100KPPH and under



Our “O” type design has the capability to reach steam outputs of up to 250,000 PPH with pressures up to 900 psi.

Features

  • Packaged boiler capacities from 10KPPH to 250 KPPH
  • Large furnace promotes low emissions
  • Engineered for long term reliability
  • Pressures up to 1,500 PSIG
  • Factory built, field erect and modular designs available
  • Radiant super heater design available
  • Suitable for natural gas and fuel oil
  • Robust long lasting design, +30 years lifespan
  • Windbox mounted fan up to 100KPPH



Tandem Steam Generating Units

Features

  • Capacities from 200kpph to 600kpph
  • Separate Furnace, Convection & Superheater modules for easy transportation
  • Pressure up to 1,500 psig
  • 100% Water cooled wall construction
  • Suitable for Nat gas, Oil, and Heat Recovery applications
  • Lowest cost of ownership



Request Flextube Watertube Specification & Information
